ICON: 1-3″ Lift Rear VS 2.5 Aluminum Series Shocks RR W/ Cdcv Pair – 2007-14 Toyota FJ Cruiser/2003-24 Toyota 4Runner/2003-23 Lexus GX

Description

ICON Vehicle Specific (VS) 2.5 Aluminum Series shocks are designed and built to give your vehicle outstanding performance off-road and a smooth ride on the street. These shocks are configured specifically for each application in both length and damping tune. Like all ICON’S Shock Absorbers, VS 2.5 Aluminum Series shocks are 100% rebuildable and 100% revalveable. For and specific applications, ICON’S unique use of a 6061 billet aluminum manifold a few inches below the top cap of the shock creates an internal Bump Zone that when used creates an additional 20% of damping force. This additional force helps prevent harsh bottom outs and controls the suspension when compressing at high velocity. The ICON CDC Valve is an externally adjustable valve that restricts oil flow into the reservoir which creates 10 levels of compression damping force ranges. If you are looking for a more user defined tune, consider looking into the Omega Series bypass shocks.

Key features:
• ICON’s CDC Valve technology allows for 10 levels of high-resolution compression adjustability with the turn of a knob
• ICON’s internal”Bump Zone” increases damping by 20% to provide more control as the shock approaches full compression
• design improves heat dissipation to reduce shock fade during prolonged use
• Premium grade 5WT shock oil for consistent suspension damping along a wide temperature range
• Nitrogen charged monotube design with reservoir
• One piece digressive piston design with vehicle specific valving for unsurpassed performance and ride quality on and off-road
• 7/8″ diameter induction hardened, chrome plated shock shaft
• PTFE lined spherical bearings and application specific mounting hardware
• 6061 aircraft grade aluminum CNC machined components
• One-piece impact extruded aluminum cylinders offer excellent corrosion resistance and consistent finish
• 100% Rebuildable
• 100% Revalveable

Installation & fitment notes:
• TECH NOTE: Compatible with 1-3″ of rear lift over stock
• TECH NOTE: Will not fit models with factory rear air suspension. Vehicles equipped with rear air suspension require rear coil conversion, ICON part number 56110, and rear coil springs, ICON part number 52700 or 52800.
• TECH NOTE: Vehicles equipped with Kinetic Dynamic Suspension System (KDSS) also require ICON rear track bar part numer 54200

Technical data:
• Shock body diameter: 2.5″
• Shaft diameter: 0.875″
• Shaft material: Chrome
• Body material: Aluminum
• Body color: Gray
• Upper mount: Eyelet
• Lower mount: Stem
• Upper mount reference: Center OF Eylet
• Lower mount reference: Shoulder OF Stem
• Damping type: Oil
• Adjustable damping: yes
• External reservoir: yes
• : no
• Bushings included: no
• Dust shield: no
• Dust boot included: no
• Coil-over springs included: no
• Application: Performance
• Service parts: 191016 – 7.5″ FINNED RESI UPGRADE KIT
• Recommended add-on: 252008 – 2.5 X 13 SHOCK BOOT BLACK (PAIR)

Fitment:
Vehicle applications (fitment):
Year Make Model Submodel Notes
——— —— ———- ———————— —–
2010–2023 Lexus GX460 —
2003–2009 Lexus GX470 —
2023 Toyota 4Runner 40th Anniversary Edition
2017–2018 Toyota 4Runner Base
2020–2021 Toyota 4Runner Base
2003–2024 Toyota 4Runner Limited
2020–2022 Toyota 4Runner Nightshade
2003–2009 Toyota 4Runner Sport
2003–2024 Toyota 4Runner SR5
2018–2024 Toyota 4Runner SR5 Premium
2010–2016 Toyota 4Runner Trail
2021–2022 Toyota 4Runner Trail
2017–2024 Toyota 4Runner TRD Off-Road
2018–2024 Toyota 4Runner TRD Off-Road Premium
2015–2024 Toyota 4Runner TRD Pro
2022–2024 Toyota 4Runner TRD Sport
2020–2022 Toyota 4Runner Venture
2007–2014 Toyota FJ Cruiser —
